| compressed air connection 1 | g 1/2 | ||
| mounting | thread-in | ||
| Type | poppet valve | ||
| nominal flow qn 1 to 2 | 3500 l/min | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 150 °c | ||
| max. medium temperature | 150 °c | ||
| Weight | 0.09 kg | ||
| seal material | fluorocaoutchouc |
| compressed air connection type 1 | internal thread | ||
| compressed air connection type 2 | external thread | ||
| compressed air connection 2 | g 1/2 | ||
| working pressure min. | 0.2 bar | ||
| min. ambient temperature | 0 °c | ||
| min. medium temperature | 0 °c | ||
| Medium | compressed air | ||
| Housing Material | brass |
