| Type | blanking plate | ||
| Standards | iso 5599-1 | ||
| working pressure max | 16 bar | ||
| max. ambient temperature | 80 °c | ||
| max. medium temperature | 80 °c | ||
| mounting screw | with hexagon socket | ||
| Material base plate | die-cast aluminum |
| frame size | iso 1 | ||
| working pressure min. | -0.9 bar | ||
| min. ambient temperature | 0 °c | ||
| min. medium temperature | 0 °c | ||
| Medium | compressed air | ||
| Weight | 0.072 kg | ||
| seal material | acrylonitrile butadiene rubber |
