| fitting type | straight fitting | ||
| Port G | m5 | ||
| port d | Ø 4 | ||
| Type | qr1-s-rpn | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 60 °c | ||
| Weight | 0.0069 kg | ||
| seal material | acrylonitrile butadiene rubber | ||
| Material release ring | polyamide | ||
| material thread | brass |
| compressed air connection type | external thread | ||
| compressed air connection type 2 | push-in fitting | ||
| Note | due to product optimisation, the delivered article may currently deviate from the dimensions shown. | ||
| working pressure min. | -0.95 bar | ||
| min. ambient temperature | 0 °c | ||
| delivery unit | 10 piece | ||
| Housing Material | brass | ||
| material tooth lock washer | stainless steel | ||
| material release ring holder | die cast zinc |
