connection 1 thread size (metric) | g1/2 | ||
Brand | legris | ||
industry | industrial manufacturing equipment | ||
technology | fluid & gas handling, process control, pneumatics | ||
valve type | axial | ||
product series | axial valves | ||
operation type | electro-pneumatic drive | ||
maximum pilot pressure | 8 bar | ||
maximum flow rate | 2.44 dm3/sec | ||
Number of ports | 2 | ||
Port size | g1/8 | ||
connection size | g1/2 | ||
orifice size | 1/2 inch | ||
for fluid type | air, oil, water | ||
maximum operating temperature | 135 °c, 275 °f | ||
Mounting type | in-line | ||
specifications met | di: 97/23/ec (module ped a - diameters greater than 25 mm), rohs, reachdi: 2006/42/ec (machinery directive), di: 2002/95/ec (rohs), rg: 1907/2006 (reach), di: 94/9/ec (atex) - for pneumatic operation versions | ||
seal material | fkm | ||
Weight | 1.093 kg, 2.405 lb | ||
region of origin | italy | ||
Operating pressure | vacuum to 10 bar |
shape | in-line | ||
division | low pressure connectors europe division | ||
Application | pneumatic, process control, safety, fluid control, plastic injection molding, rubber industry, textile, printing, packaging, robotics | ||
product type | axial valves | ||
product style | female axial valve | ||
function | 2-way, normally closed | ||
maximum operating pressure | 10 bar, 1 mpa, 145.04 psi | ||
minimum pilot pressure | 4.2 bar | ||
flow rate | 2.44 dm3/sec | ||
port type | thread | ||
connection type | bspp | ||
port connection | g1/8 | ||
configuration | 2/2 | ||
media | air, oil, water | ||
minimum operating temperature | -20 °c, -4 °f | ||
actuation type | air pilot | ||
body material | nickel plated brass | ||
o-ring material | fkm | ||
quantity per box | 1 | ||
vacuum pressure rating | 740 mm-hg |
