hose i.d. (size) | -8 | ||
media | hydraulic fluids, petroleum & water-glycol based fluids, lubricating oils, air & water, fuels (check fuel type with our catalogue chart)., coolants i.e. glycol, industrial air, lubricants, water, mineral hydraulic oil | ||
Brand | parker | ||
industry | industrial manufacturing equipment, off-road machinery, transportation | ||
technology | fluid & gas handling | ||
product style | no-skive | ||
hose inside diameter | 12.7 mm, 1/2 inch | ||
minimum bend radius | 180 mm, 7.087 inch | ||
cover color | black | ||
maximum operating temperature | 100 °c (water: 85 , air: 70), 212 °f (water: 185, air: 158) | ||
materials of construction | rubber | ||
hose inner tube material | synthetic rubber | ||
Weight | 0.67 kg/m, 0.45 lb/ft |
hose cover type | galvanised steel wire | ||
minimum operating temperature | -40 °f, -40 °c | ||
division | polymer hose division europe | ||
Application | machine tool, glass industry | ||
product type | hydraulic hose, specialty hose | ||
maximum operating pressure | 13.8 mpa, 2000 psi, 138 bar | ||
hose outside diameter | 22 mm, 0.866 inch | ||
design factor | 4:1 | ||
compatible fitting | 48 series | ||
specifications met | sae 100 r1at | ||
cover material | galvanized steel wire | ||
hose reinforcement material | 1 high-tensile steel wire braid |
