activation | electrically | ||
switching principle | 5/2 | ||
working pressure min. | 1.5 bar | ||
dc operating voltage | 24 v | ||
Manual override | with detent, without detent | ||
electrical connection size | en 175301-803, form a | ||
pilot | internal | ||
valve plug connector | with valve plug connector | ||
connection type | pipe connection | ||
blocking principle | plate principle, single base plate principle | ||
temperature resistance | -25 °c cold-resistant | ||
max. ambient temperature | 50 °c | ||
max. medium temperature | 50 °c |
nominal flow qn | 700 l/min | ||
compressed air connection output | Ø 8x1 | ||
working pressure max | 10 bar | ||
voltage tolerance dc | -10% / +10% | ||
electrical connection type | plug | ||
Sealing principle | soft seal | ||
valve type | diaphragm poppet valve | ||
throttle | with throttle | ||
return | with air spring return | ||
can be assembled into blocks | can be assembled into blocks | ||
min. ambient temperature | -25 °c | ||
min. medium temperature | -25 °c |
Stock | 8 uds. |
---|---|
Referencia | 5727400220 |
Fabricante | AVENTICS |
Unidades | Precio / Unidad |
---|---|
1 - 4 | $170,93 |
5+ | $167,51 |
