| product style | carstick® not removable cartridge | ||
| compatible fitting material | elastic polymers, brass, aluminum | ||
| Brand | parker, legris | ||
| industry | industrial manufacturing equipment, eletronics & semiconductor, food & beverages, life sciences, power generation & renewable energy | ||
| technology | fluid & gas handling | ||
| product series | carstick® | ||
| vacuum pressure rating | 755 mm-hg, 29.72 inch-hg | ||
| configuration | tube to port | ||
| connection 1 size | 6 mm (o.d) | ||
| maximum operating temperature | 130 °c, 266 °f | ||
| for fluid type | compressed air, drinking waters, beverages, hydrogen, inert gas, steam, cooling liquids, oxygen | ||
| gripping ring material | stainless steel | ||
| package type | tube packaging | ||
| body material | technical polymer |
| tube outside diameter | 6 mm | ||
| o-ring material | epdm | ||
| division | low pressure connectors europe | ||
| Application | water treatment, electronics, semiconductor, automotive, food&beverage | ||
| product type | push-to-connect cartridges | ||
| maximum operating pressure | up to 232 psi, up to 16 bar | ||
| shape | straight | ||
| connection 1 type | tube | ||
| connection 2 type | housing | ||
| minimum operating temperature | -20 °c, -4 °f | ||
| seal material | epdm | ||
| quantity per box | 50 | ||
| connection type | push-in |
