753093 Festo

FESTO 753093 Intensificador de presión

DSBC/G-100- -

$270,67 5 uds. con envío de 1 a 3 días a United States

Especificaciones

Stroke 1mm
Operating Pressure 0,05 bar ... 12 bar
Mounting Position optional
Conexion neumatica G1/2
Peso 3566 7866
Stroke 1 mm ... 2.800 mm
Piston rod thread M12 M20x1.5
Based on standard ISO 15552
Mounting position optional
Piston-rod end Male thread Female thread
Position detection Via proximity switch
Variants For unlubricated operation Clamping unit attached End-position locking at both ends End-position locking with piston rod in retracted position End-position locking with piston rod in advanced position Increased chemical resistance Bellows on bearing cap Hard scraper Extended male piston rod thread Piston rod with female thread Extended piston rod Low friction for balancer applications Metal scraper With protection against rotation Uniform, slow movement Low friction Through piston rod Heat-resistant seals max. 120°C Sensor slots on 3 profile sides Temperature range 0 to 150°C Temperature range -40 to 80°C Piston rod at one end
Static holding force of clamping unit 5.000 N
Clamping unit release pressure 3 bar
Static holding force of end-position locking 5.000 N
Unlocking pressure ≥ 1,5 bar
Operating pressure 0,05 bar ... 12 bar
CE mark (see declaration of conformity) To EU Explosion Protection Directive (ATEX)
Explosion protection Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX)
ATEX category dust II 2D
Explosion ignition protection type for dust Ex h IIIC T120°C Db
Explosion protection certification outside the EU EPL Db (GB) EPL Gb (GB)
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Ambient temperature -40 °C ... 150 °C
Cushioning length 0 mm ... 31 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 4.418 N
Moving mass for 0 mm stroke 800 g ... 1.941 g
Basic weight for 0 mm stroke 3.566 g ... 7.866 g
Additional weight per piston rod extension of 10 mm 39 g
Type of mounting Via female thread With accessories Either:
Note on materials Contains paint-wetting impairment substances RoHS-compliant
Material spring Spring steel High-alloy stainless steel
Material housing end-position locking Anodised wrought aluminium alloy
Material clamping jaws clamping unit Brass
Material piston end-position locking Hardened steel
Material piston rod High-alloy stainless steel, hard chrome-plated High-alloy steel High-alloy stainless steel
Buffer seal material FPM TPE-U(PU)
Material cylinder barrel Smooth-anodised wrought aluminium alloy
Material rod wiper Brass PTFE reinforced
Material collar screws Galvanised steel
Piston diameter 100 mm
Torsional backlash at piston rod +/- -0,45 deg ... 0,45 deg
Cushioning Elastic cushioning rings/plates at both ends Self-adjusting pneumatic end-position cushioning Pneumatic cushioning, adjustable at both ends
Conforms to standard ISO 15552
Design Piston Piston rod Profile barrel
Symbol 00991217 00991218 00991235 00991237 00991257 00991258 00991907 00991910 00992970 00992971
Mode of operation clamping unit Retracting Advancing Static Released through compressed air Frictional clamping with spring force
Axial backlash clamping unit 0,8 mm
Mode of operation end-position locking Positive interlocking with stop cylinder Released through compressed air
Axial backlash end-position locking 1,5 mm
Locking pressure ≤ 0,5 bar
Mode of operation Double-acting
CE marking (see declaration of conformity) To UK EX instructions
ATEX category gas II 2G
Explosion ignition protection type for gas Ex h IIC T4 Gb
Explosion ambient temperature -20°C <= Ta <= +60°C
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC 2 - Moderate corrosion stress 3 - high corrosion stress
Impact energy in end positions 1,25 J ... 2,5 J
Max. torque for protection against torsion 3 Nm
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 4.418 N ... 4.712 N
Additional moving mass per 10 mm stroke 32 g ... 78 g
Additional weight per 10 mm stroke 94 g ... 201 g
Additional weight per piston rod thread extension of 10 mm 22 g
Pneumatic connection G1/2
Material cover Die-cast aluminium, coated
Clamping unit housing material Anodised wrought aluminium alloy
Material piston seal FPM HNBR TPE-U(PU)
Piston clamping unit material POM
Material piston Wrought aluminium alloy
Material piston rod wiper FPM HNBR PE TPE-U(PU)
Cushioning piston material Aluminium POM
Material nut Galvanised steel
Material bearing Bronze Metal polymer compound POM
Material bellows NBR PA
