DSL101C Parker Hannifin

Parker DSL101C

$303,58 1 uds. con envío de 1 a 3 días a United States

Especificaciones

max. presion 3600 psi, 250 bar
max. flujo 15 gal/min, 60 l/min
Junta d-ring (standard)
Peso 200g
flow rate 15 gal/min, 60 l/min
configuration normally closed
seal material d-ring (standard)
division hydraulic cartridge systems division
Mounting type screw in cartridge valve
operation type solenoid operated
leak rate 5 drops/min
function 2-way
for fluid type mineral-based or synthetic hydraulic fluids
filter efficiency rating iso 4406 18/16/13, sae class 4
installation torque 37-41 lb-ft, 50-56 nm
Operating temperature -35 to +200 °f, -37 to +93 °c
minimum operating temperature -35 °f, -37 °c
Input voltage 85% of rated voltage at 72°f (20°c) min
Weight 0.41 lb, 0.2 kg
maximum inlet pressure rating 3600 psi, 250 bar
actuation type electrical
wire mesh screen included no
maximum flow rate 15 gal/min, 60 l/min
Flow direction side to nose (2-1)
maximum operating pressure 3600 psi, 250 bar
cavity size c10-2
free reverse flow no
maximum kinematic viscosity 45-2000 ssu (6 to 420 cst)
valve material all parts steel. all operating parts hardened steel
coil nut tightening torque 5-7 lb-ft, 7-10 nm
maximum operating temperature +200 °f, +93 °c
coil type 5/8" super coil
response time 80 ms
