| Diameter lubrication hole (outer ring) | M | 6 | mm |
| Chamfer dimension outer ring | r1,2 | min.1 | |
| Outside diameter | d2 | 230 | mm |
| Width Outer ring | C | 80 | mm |
| Raceway diameter inner ring | F | 200 | mm |
| Width annular lubrication groove at inner ring | b1 | 13,50 | mm |
| Chamfer dimension bore | r1 | min.1 | |
| Bore diameter | d | 160 | mm |
| Nominal width | B | 105 | mm |
| Angle of tilt | α | 8 | ° |
| Width annular lubrication groove at outer ring | b | 13,50 | mm |
| Fabricante | Referencia |
|---|---|
| INA | GE160-DO-2RS (INA) |
