Especificaciones
Ancho | 24mm |
---|---|
Diámetro interior | 70mm |
Diámetro exterior | 125mm |
---|---|
Peso | 1,31Kg |
Shoulder diameter inner ring | d1 | 89,10 | mm |
Contact angle | α | 35 | ° |
Shoulder diameter outer ring | D1 | 106,30 | mm |
Distance between the apexes of the pressure cones | a | 68 | mm |
Minimum chamfer dimension | rmin | 1,50 | mm |
Bore diameter | d | 70 | mm |
Width | B | 24 | mm |
Basic static load rating, radial | C0r | 114,000 | |
Limiting speed | nG | 10,700 |
Outside diameter | D | 125 | mm |
Basic dynamic load rating, radial | Cr | 118,000 | |
Fatigue load limit, radial | Cur | 8,700 | |
Reference speed | nϑr | 4,700 |
Minimum diameter shaft shoulder | da min | 79 | mm |
Maximum fillet radius | ra max | 1,50 | mm |
Maximum diameter of housing shoulder | Da max | 116 | mm |
Stock | 50+ uds. |
---|---|
Referencia | QJ214-XL-MPA |
Fabricante | FAG |
Unidades | Precio / Unidad |
---|---|
1 - 4 | $196,94 |
5 - 9 | $193,01 |
10 - 14 | $189,07 |
15+ | $185,12 |
