a)
Air connection*) M5 on two sides for release pressure
b)
Connection*) M5 on two sides for Plus-Air connection or air filter
c)
Adjusting screw on two sides
d)
Spacer plate (accessory) for MKS
e)
Air filter: connection M5 (possible on two sides)
*) Only one connection needed.
All connections sealed upon delivery.
| A | 128 | mm | |
| B | 49 | ||
| D | 30 | mm | |
| E2 | 30 | mm | |
| F1 | 17 | mm | |
| F3 | 17 | mm | |
| H | 70 | mm | |
| H2 | 40 | mm | |
| S2 | M10 |
| A1 | 86,80 | mm | |
| B1max | 82,50 | mm | |
| E1 | 30 | mm | |
| E3 | 9,50 | mm | |
| F2 | 29,50 | mm | |
| F4 | 19,50 | mm | |
| H1 (Ball runner block .H. (...high...) Spacer plate necessary.) | 57 | mm | |
| N3 | 15 | mm | |
| X | 5,50 | mm |
| Spring energy holding force with standard air port (Holding force by spring energy. The inspection is done in a mounted state with a lubricated layer (ISO-VG 68). ) | 1.450 | N | |
| Air consumption (normal liter) standard air port | 0,04 | dm³/stroke | |
| Max. pneumatic operating pressure | 8 | bar | |
| Mass | 2,08 | kg | |
| Size | 55 |
| Spring energy holding force with air-plus port (Increased holding force by additional air admission at air-plus port with 6.0 bar. Circuit across 5/2- or 5/3-way directional control valve. ) | 3.300 | N | |
| Air consumption (normal liter) air-plus port | 0,18 | dm³/stroke | |
| Release pressure min. | 5,50 | bar | |
| Operating conditions | Operating conditions | ||
| Permissible ambient temperature (min ... max) | 0 °C ... +70 °C |
