| parts | distributor, non-return valve | ||
| air supply | right | ||
| Version | distributor 1x | ||
| working pressure min. | 0 bar | ||
| min. ambient temperature | -10 °c | ||
| Medium | compressed air, neutral gases | ||
| nominal flow 1 ▶ 3 | 1000 l/min | ||
| Housing Material | polyamide | ||
| seal material | acrylonitrile butadiene rubber |
| port | g 1/4 | ||
| Type | can be assembled into blocks | ||
| mounting orientation | any | ||
| working pressure max | 12 bar | ||
| max. ambient temperature | 50 °c | ||
| nominal flow qn 1 to 2 | 800 l/min | ||
| Weight | 0.178 kg | ||
| material front plate | acrylonitrile butadiene styrene |
