Note on materials | RoHS-compliant | ||
Grid dimension | 16 mm | ||
Operating pressure | -0,9 bar ... 10 bar | ||
Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
Max. tightening torque for valve mounting | 0,65 Nm | ||
Product weight | 118 g | ||
Pneumatic connection, port 3 | G1/4 |
Material manifold | Wrought aluminium alloy | ||
Max. number of valve positions | 16 | ||
Approval | RCM trademark c UL us - Recognized (OL) | ||
Max. tightening torque H-rail mounting | 1,5 Nm | ||
Max. tightening torque wall mounting | 3 Nm | ||
Pneumatic connection, port 1 | G1/4 | ||
Pneumatic connection, port 5 | G1/4 |
